| BIOS Features | ACPI 6.4SMBIOS 3.5 or laterUEFI 2.8Plug and Play (PnP)USB Keyboard support |
|---|---|
| Audio | ALC 888S HD Audio |
| TPM | 1 TPM Header |
| Network Controllers | Dedicated LAN for IPMI, Dual LAN with Intel i210 Gigabit Ethernet ControllerSingle LAN with ASPEED AST2600 BMC |
| M.2 | M.2 Interface: 2 PCIe 5.0 x4, RAID 0 & 1Form Factor: 2280/22110Key: M-Key |
| Chipset | B650 |
| DIMM Sizes | 16GB, 24GB, 32GB, 48GB, 8GB |
| BIOS Type | AMI 32MB SPI Flash EEPROM |
| Video Output | 1 DP 1.4a port(s), 1 HDMI 2.0 port(s), 2 rear type C port(s) DP 1.4 Alt mode |
| Dimension | 9.6" x 9.6" (24.384cm x 24.384cm) |
| PCIe | 1 PCIe 4.0 x4, 2 PCIe 5.0 x16 slots (16/NA or 8/8) |
| Form Factor | Micro-ATX |
| Memory Type | 5200/4800/3600 MT/s Up to 192GB of memory with speeds of up to 5200MT/s (1DPC)/ 3600MT/s (2DPC) |
| Application | Server |
| IPMI | ASPEED AST2600 BMC |
| Memory Voltage | 1.1V |
| CPU | AMD EPYC 4004 series ProcessorsSingle Socket LGA-1718 (Socket AM5) supported, CPU TDP supports Up to 170W TDP |
| Serial Port | 1 COM Port(s) (1 header) |
| SATA | 4 SATA3 ports; RAID 0, 1, 10 |
| Memory Capacity | 4 DIMM slots |
| Core | 32 threads, Up to 16 cores |
Supermicro MBD-H13SAE-MF-B
The Supermicro MBD-H13SAE-MF-B motherboard is designed for high-performance computing, featuring AMD EPYC 9004 series processors, PCIe 5.0, and DDR5 memory. Key features include 12 DIMM slots supporting up to 6TB RAM, 4 PCIe 5.0 x16 slots, and 2 NVMe ports. Benefits include enhanced data center efficiency, scalability, and flexibility. Unique selling points are its optimized performance for demanding workloads and robust security features.
$Quote5 pcs (MOQ)
| BIOS Features： | ACPI 6.4SMBIOS 3.5 or laterUEFI 2.8Plug and Play (PnP)USB Keyboard support |
|---|---|
| Audio： | ALC 888S HD Audio |
| TPM： | 1 TPM Header |
| Network Controllers： | Dedicated LAN for IPMI, Dual LAN with Intel i210 Gigabit Ethernet ControllerSingle LAN with ASPEED AST2600 BMC |
| M.2： | M.2 Interface: 2 PCIe 5.0 x4, RAID 0 & 1Form Factor: 2280/22110Key: M-Key |
