SAMSUNG 970 EVO PLUS M.2 2280 250GB PCIe Gen 3.0 x4, NVMe 1.3 V-NAND 3-bit MLC Internal Solid State Drive (SSD) MZ-V7S250BW

Power Consumption (Active)：	Average: 5W, Maximum: 8W (Burst mode)
Memory Components：	V-NAND 3-bit MLC
Width：	22.15mm
Max Shock Resistance：	1 500G & 0.5 ms (Half sine)
Form Factor：	M.2 2280

Power Consumption (Active)：

Average: 5W, Maximum: 8W (Burst mode)

Memory Components：

V-NAND 3-bit MLC

Width：

22.15mm

Max Shock Resistance：

1 500G & 0.5 ms (Half sine)

Form Factor：

M.2 2280

SSD 970 EVO PLUS: Endurance and stratospheric performance

The Samsung 970 EVO Plus 250 GB SSD helps transform the performance and responsiveness of your machine. Benefiting from increased speeds and very high endurance compared to previous generation SSDs, the Samsung 970 EVO Plus in M.2 2280 format is based on the PCI-E 3.0 x4 interface as well as on technology NVMe 1.3. It is also equipped with TLC memory, a Samsung Phoenix controller and 512 MB of LPDDR4 cache memory.

The Samsung 970 EVO Plus M.2 PCIe 3.0 4x NVMe 1.3 in its 250 GB version takes your PC to another level of performance thanks to its speeds of up to 3.5 GB/s in reading and 3.2 GB/s in writing. The number of operations per second reaches an impressive level of 370,000 IOPS in reading and 450,000 IOPS in writing (4KB, QD32), enough to launch your applications without latency.

GO BEYOND THE LIMITS

With the 970 EVO Plus range you assemble a configuration for ultimate performance all with a disk in M.2 type 2280 format. Thanks to firmware optimizations and Intelligent TurboWrite technology, it offers speeds of up to 3500 MB/s in reading and 3300 MB/s writing, i.e. 53% faster depending on the model.

TAKE A NEW COURSE

The 970 EVO Plus range is equipped with a PCIe 3.0 x4 NVMe 1.3 interface and offers in-house 3-bit V-NAND and an improved Phoenix controller. The drive can reach speeds of up to 3500MB/s read and up to 3300MB/s write flawlessly (varies by model) for faster boot times and ever faster transfers.

EXCEPTIONAL ENDURANCE

The 970 EVO Plus SSDs offered by Samsung set a new standard in terms of endurance thanks to the Samsung V-NAND 3-bit memory chips. The 250 GB version allows 150 TB of writing while the 2 TB version reaches 1200 TB. These SSDs are therefore ideal for boosting boot times and access times to your applications and for handling heavy files from an editing station. .

SAMSUNG MAGICIAN

Samsung Magician software is designed to help you manage your SSD with a simple and intuitive user interface. Receive notifications when new firmware is released and easily install updates to improve your SSD’s performance, stability, and compatibility. Check your SSD’s read and write speeds and maintain the highest performance. Select your security options to protect your data.

Power Consumption (Active)	Average: 5W, Maximum: 8W (Burst mode)
Memory Components	V-NAND 3-bit MLC
Width	22.15mm
Max Shock Resistance	1 500G & 0.5 ms (Half sine)
Form Factor	M.2 2280
4KB Random Write	QD1: Up to 60 000 IOPS, QD32: Up to 550 000 IOPS
Max Sequential Read	Up to 3500 MB/s
Capacity	250GB
Brand	SamSung
Used For	Consumer
Depth	80.15mm
4KB Random Read	QD1: Up to 17 000 IOPS, QD32: Up to 250 000 IOPS
Model	MZ-V7S250BW
Series	Samsung 970 EVO PLUS
Features	Always Evolving SSD, Design Flexibility, Exceptional Endurance, Level up Performance, Reliability: 150 TBW, Samsung Magician, The new standard in sustainable performance. The 970 EVO Plus provides exceptional endurance powered by the latest V-NAND technology and Samsung's reputation for quality., Unparalleled Reliability
Cache	Samsung 512MB Low Power DDR4 SDRAM
Interface	PCIe 3.0 x4 NVMe 1.3
Power Consumption (Idle)	Max. 30 mW
MTBF	1 500 000 hours
Application	Desktop
Device Type	Internal Solid State Drive (SSD)
Products Status	New
Max Sequential Write	Up to 2300 MB/s
Height	2.38mm
Weight	8.00g
Operating Temperature	0C ~ +70C
Controller	Samsung Phoenix
